Paper Tray Forming Machine with Glue Sprayer System
  • LZ-1200S
  • Paper Tray Forming Machine with Glue Sprayer System
    • Produce speed : 60-180pcs/min
    • Weight : 2200kgs
    • Size : 3600*1400*1500mm
    • Most of the high quality sealed bearings, (to prevent dust, liquid into the bearing life) long life, good stability.
    Inquiry

    Product Details

    LZ-1200S is an ideal equipment to produce paper box such like hamburger box, chips box, fried chicken box,kids meal box, fast food box, fast noodles box etc.With firm structure, high quality, low noise and high efficiency.

    It has paper feeding unit, adjusted unit, glue unit, forming unit, finished products collecting unit and also counting unit. Whole machine use the imported brand electric appliance, such as French Schneider, Japan Omron and Germany Siemens.

    Device for feeding Water-based adhesive(glue). High efficiency and high precision to feeding glue and the sealing edge of the carton can be adjustable, its device design reasonable, compact form and running steadily, easy and convenience to clean.Finished carton outing device.

    Full automatic carton outing device (feeding, collection, stacking) and fixing with counting, convenient for packing and save of labors. Photoelectric failure-detecting system is available, if there is no papers or paper feeding blocking, the machine will stop by it self. So it can reduce the cost consume, and increase more safety performance.

    Techical Specification

    Main Technical Parameters
    Machine Model LZ-1200S
    Producktion speed 60-180pcs/min(according to different box shape)
    Raw material 180-600gsm, cardboard, coated paper, kraft paper, corrugated paper
    Paper thickness 200-600g/M white paper/corrugating paper thick corrugated paper 1.5mm
    Paper size L: 100-450mm
    W:100-600mm
    H:15-200mm
    Degree of taper 5° -40°
    Air source 2kgs/cm2
    Power 5.5KW
    Overall Dimension 3600*1400*1500mm
    Weight 2.2T

    Finished Products
